基于 Jupyter Notebook · 无代码搭建完整 AI 自动化流程
英文名:agentic-rag-for-dummies
⭐ 3.3k Stars 🍴 440 Forks 💻 Jupyter Notebook 📄 MIT 🏷 AI 8.2分
8.2AI 综合评分
RAGAgentLangGraph工作流学习教程
✦ AI Skill Hub 推荐

AI Skill Hub 强烈推荐:agentic-rag-for-dummies Agent工作流 是一款优质的Agent工作流。已获得 3.3k 颗 GitHub Star,AI 综合评分 8.2 分,在同类工具中表现稳健。如果你正在寻找可靠的Agent工作流解决方案,这是一个值得深入了解的选择。

📚 深度解析

agentic-rag-for-dummies Agent工作流 是一套完整的 AI Agent 自动化工作流方案。随着 AI 能力的不断提升,基于 Agent 的自动化工作流正在成为提升个人和团队效率的核心方式。区别于传统的 RPA 自动化(模拟鼠标键盘操作),AI Agent 工作流通过理解任务意图、动态规划执行路径,能够处理更复杂的非结构化任务。

agentic-rag-for-dummies Agent工作流 工作流的设计遵循"最小配置,最大复用"原则:核心逻辑已经封装好,用户只需配置自己的 API Key 和业务参数即可快速上手。工作流内置错误处理和重试机制,在网络波动或 API 限速等情况下仍能稳定运行,适合作为生产环境的自动化基础设施。

在实际部署时,建议先在测试环境中运行 3-5 次,验证各个环节的输出结果符合预期,再部署到生产环境。AI Skill Hub 评分 8.2 分,是同类 Agent 工作流中的精选推荐。

📋 工具概览

基于LangGraph构建的模块化智能RAG系统,提供完整的检索增强生成工作流。通过Jupyter Notebook详细教学,适合想学习Agent AI和RAG技术的开发者快速上手和实践。

agentic-rag-for-dummies Agent工作流 是一套完整的 AI Agent 自动化工作流方案。通过可视化的节点编排,将复杂的多步骤任务拆解为清晰的自动化流程,实现全程无人值守的智能处理。支持与数百种外部服务和 API 无缝集成,适合构建数据处理管线、业务自动化和 AI 辅助决策系统。

GitHub Stars
⭐ 3.3k
开发语言
Jupyter Notebook
支持平台
Windows / macOS / Linux
维护状态
持续维护,定期更新
开源协议
MIT
AI 综合评分
8.2 分
工具类型
Agent工作流
Forks
440

📖 中文文档

以下内容由 AI Skill Hub 根据项目信息自动整理,如需查看完整原始文档请访问底部「原始来源」。

基于LangGraph构建的模块化智能RAG系统,提供完整的检索增强生成工作流。通过Jupyter Notebook详细教学,适合想学习Agent AI和RAG技术的开发者快速上手和实践。

agentic-rag-for-dummies Agent工作流 是一套完整的 AI Agent 自动化工作流方案。通过可视化的节点编排,将复杂的多步骤任务拆解为清晰的自动化流程,实现全程无人值守的智能处理。支持与数百种外部服务和 API 无缝集成,适合构建数据处理管线、业务自动化和 AI 辅助决策系统。

📌 核心特色
  • 可视化 Agent 工作流编排,无需编写复杂代码
  • 支持多步骤自动化任务链,实现全流程无人值守
  • 与外部 API、数据库和第三方服务无缝集成
  • 内置错误处理与自动重试机制,保障稳定运行
  • 提供可复用的自动化模板,快速在同类场景部署
🎯 主要使用场景
  • 自动化日常重复性工作,将精力集中于创造性任务
  • 构建数据采集 → 处理 → 输出的完整自动化管线
  • 实现跨平台、跨系统的数据流转和业务协同
以下安装命令基于项目开发语言和类型自动生成,实际以官方 README 为准。
安装命令
# 克隆仓库
git clone https://github.com/GiovanniPasq/agentic-rag-for-dummies
cd agentic-rag-for-dummies

# 查看安装说明
cat README.md

# 按 README 完成环境依赖安装后即可使用
📋 安装步骤说明
  1. 访问 GitHub 仓库获取工作流文件
  2. 在对应平台(Dify / Flowise / Make 等)中找到「导入工作流」功能
  3. 上传工作流文件
  4. 按照提示配置必要的环境变量和 API Key
  5. 运行测试确认流程正常后投入使用
以下用法示例由 AI Skill Hub 整理,涵盖最常见的使用场景。
常用命令 / 代码示例
# 查看帮助
agentic-rag-for-dummies --help

# 基本运行
agentic-rag-for-dummies [options] <input>

# 详细使用说明请查阅文档
# https://github.com/GiovanniPasq/agentic-rag-for-dummies
以下配置示例基于典型使用场景生成,具体参数请参照官方文档调整。
配置示例
# agentic-rag-for-dummies 配置说明
# 查看配置选项
agentic-rag-for-dummies --config-example > config.yml

# 常见配置项
# output_dir: ./output
# log_level: info
# workers: 4

# 环境变量(覆盖配置文件)
export AGENTIC_RAG_FOR_DUMMIES_CONFIG="/path/to/config.yml"
📑 README 深度解析 真实文档 完整度 84/100 查看 GitHub 原文 →
以下内容由系统直接从 GitHub README 解析整理,保留代码块、表格与列表结构。

简介

<p align="center"> <img alt="Agentic RAG for Dummies Logo" src="assets/logo.png" width="350px"> </p>

Agentic RAG for Dummies

<p align="center"> <strong>Build a modular Agentic RAG system with LangGraph, conversation memory, and human-in-the-loop query clarification</strong> </p>

<p align="center"> <a href="#overview">Overview</a> • <a href="#how-it-works">How It Works</a> • <a href="#llm-provider-configuration">LLM Providers</a> • <a href="#implementation">Implementation</a> • <a href="#installation--usage">Installation & Usage</a> • <a href="#troubleshooting">Troubleshooting</a> </p>

<p align="center"> <img src="https://img.shields.io/github/stars/GiovanniPasq/agentic-rag-for-dummies?style=social" alt="GitHub Stars"/> <img src="https://img.shields.io/github/forks/GiovanniPasq/agentic-rag-for-dummies?style=social" alt="GitHub Forks"/> <img src="https://img.shields.io/badge/license-MIT-green" alt="License"/> <a href="https://github.com/von-development/awesome-langgraph"> <img src="https://awesome.re/badge.svg" alt="Awesome LangGraph"/> </a> </p>

<p align="center"> <img src="https://img.shields.io/badge/python-3.11%2B-blue?logo=python&logoColor=white" alt="Python"/> <img src="https://img.shields.io/badge/LangGraph-1.2%2B-orange?logo=langchain&logoColor=white" alt="LangGraph"/> <img src="https://img.shields.io/badge/Qdrant-vector%20db-DC244C" alt="Qdrant"/> <img src="https://img.shields.io/badge/LLM%20Providers-Ollama%20%7C%20OpenAI%20%7C%20Anthropic%20%7C%20Google-purple" alt="LLM Providers"/> </p>

<p align="center"> <a href="https://colab.research.google.com/github/GiovanniPasq/agentic-rag-for-dummies/blob/main/notebooks/agentic_rag.ipynb"> <img src="https://colab.research.google.com/assets/colab-badge.svg" alt="Open In Colab"/> </a> </p>

<p align="center"> <img alt="Agentic RAG Demo" src="assets/demo.gif" width="650px"> </p>

<p align="center"> <strong>If you like this project, a star ⭐️ would mean a lot :)</strong><br> </p>

Overview

This repository demonstrates how to build an Agentic RAG (Retrieval-Augmented Generation) system using LangGraph with minimal code. Most RAG tutorials show basic concepts but lack guidance on building modular, agent-driven systems — this project bridges that gap by providing both learning materials and an extensible architecture.

What's inside

FeatureDescription
🗂️ **Hierarchical Indexing**Search small chunks for precision, retrieve large Parent chunks for context
🧠 **Conversation Memory**Maintains context across questions for natural dialogue
❓ **Query Clarification**Rewrites ambiguous queries or pauses to ask the user for details
🤖 **Agent Orchestration**LangGraph coordinates the full retrieval and reasoning workflow
🔀 **Multi-Agent Map-Reduce**Decomposes complex queries into parallel sub-queries
✅ **Self-Correction**Re-queries automatically if initial results are insufficient
🗜️ **Context Compression**Keeps working memory lean across long retrieval loops
🔍 **Observability**Track LLM calls, tool usage, and graph execution with Langfuse
📊 **Evaluation**Evaluate retrieval and answer quality with RAGAS metrics

Install Ollama from https://ollama.com

ollama pull granite4.1:8b

python from langchain_ollama import ChatOllama

llm = ChatOllama(model="granite4.1:8b", temperature=0, seed=42) ``` > ⚠️ For reliable tool calling and instruction following, prefer models 8B+. Smaller models may ignore retrieval instructions or hallucinate. See Troubleshooting.

---

Step 1: Initial Setup and Configuration

Define paths and initialize core components.

import os
from pathlib import Path
from langchain_huggingface import HuggingFaceEmbeddings
from langchain_qdrant.fastembed_sparse import FastEmbedSparse
from qdrant_client import QdrantClient

DOCS_DIR = "docs"  # Directory containing your pdf files
MARKDOWN_DIR = "markdown_docs" # Directory containing the pdfs converted to markdown
PARENT_STORE_PATH = "parent_store"  # Directory for parent chunk JSON files
CHILD_COLLECTION = "document_child_chunks"
DEFAULT_RETRIEVAL_K = 7
CHILD_CHUNK_SEPARATOR = "\n\n<CHILD_CHUNK_BOUNDARY>\n\n"

os.makedirs(DOCS_DIR, exist_ok=True)
os.makedirs(MARKDOWN_DIR, exist_ok=True)
os.makedirs(PARENT_STORE_PATH, exist_ok=True)

from langchain_ollama import ChatOllama
llm = ChatOllama(model="granite4.1:8b", temperature=0, seed=42)

dense_embeddings = HuggingFaceEmbeddings(model_name="Qwen/Qwen3-Embedding-0.6B")
sparse_embeddings = FastEmbedSparse(model_name="Qdrant/bm25")

client = QdrantClient(path="qdrant_db")

---

Step 9: Build Graph Node and Edge Functions

Create the processing nodes and edges for the LangGraph workflow.

#### Main Graph Nodes & Edges

from langgraph.types import Send, Command
from langchain_core.messages import HumanMessage, AIMessage, SystemMessage, RemoveMessage, ToolMessage
from typing import Literal, Set

MAIN_HISTORY_MESSAGES_TO_KEEP = 4
if MAIN_HISTORY_MESSAGES_TO_KEEP < 2:
    raise ValueError("MAIN_HISTORY_MESSAGES_TO_KEEP must be at least 2.")
PRE_ANSWER_HISTORY_MESSAGES_TO_KEEP = max(MAIN_HISTORY_MESSAGES_TO_KEEP - 1, 0)

def _is_plain_conversation_message(msg) -> bool:
    return (
        isinstance(msg, (HumanMessage, AIMessage))
        and not getattr(msg, "tool_calls", None)
        and not getattr(msg, "name", None)
    )

def _name_internal_message(message, name):
    """Tag a subgraph-only message so it is not treated as chat history."""
    return message.model_copy(update={"name": name})

def _retrieval_contexts(messages) -> list[str]:
    contexts = []
    ignored_prefixes = (
        "NO_RELEVANT_CHUNKS",
        "NO_PARENT_DOCUMENT",
        "RETRIEVAL_ERROR:",
        "PARENT_RETRIEVAL_ERROR:",
    )
    for message in messages:
        if not isinstance(message, ToolMessage):
            continue
        content = str(message.content).strip()
        if content and not content.startswith(ignored_prefixes):
            parts = content.split(CHILD_CHUNK_SEPARATOR) if message.name == "search_child_chunks" else [content]
            contexts.extend(part for part in parts if part)
    return list(dict.fromkeys(contexts))

def _format_conversation(messages) -> str:
    lines = []
    for msg in messages:
        role = "User" if isinstance(msg, HumanMessage) else "Assistant"
        lines.append(f"{role}: {msg.content}")
    return "\n".join(lines)

def _remove_messages_not_in(messages, keep_ids):
    removals = []
    for msg in messages:
        msg_id = getattr(msg, "id", None)
        if isinstance(msg, SystemMessage) or not msg_id:
            continue
        if msg_id not in keep_ids:
            removals.append(RemoveMessage(id=msg_id))
    return removals

def _recent_conversation(messages, pending_query="") -> list:
    """Return recent context before the current user message."""
    plain_messages = [msg for msg in messages if _is_plain_conversation_message(msg)]
    recent_messages = plain_messages[:-1]

    if pending_query:
        for index in range(len(recent_messages) - 1, -1, -1):
            msg = recent_messages[index]
            if isinstance(msg, HumanMessage) and str(msg.content).strip() == pending_query:
                return recent_messages[:index]

    return recent_messages

def summarize_history(state: State):
    messages = state.get("messages", [])
    updates = {"agent_answers": [{"__reset__": True}]}

    if not messages:
        return updates

    plain_messages = [msg for msg in messages if _is_plain_conversation_message(msg)]
    keep_count = PRE_ANSWER_HISTORY_MESSAGES_TO_KEEP
    messages_to_summarize = plain_messages[:-keep_count] if len(plain_messages) > keep_count else []
    keep_ids = {getattr(msg, "id", None) for msg in plain_messages[-keep_count:]}
    keep_ids.discard(None)

    removals = _remove_messages_not_in(messages, keep_ids)
    if removals:
        updates["messages"] = removals

    if not messages_to_summarize:
        return updates

    existing_summary = state.get("conversation_summary", "").strip()
    conversation = "Existing summary:\n"
    conversation += f"{existing_summary or '(none)'}\n\n"
    conversation += "New messages to merge into the summary:\n"
    conversation += _format_conversation(messages_to_summarize)

    summary_response = llm.invoke([
        SystemMessage(content=get_conversation_summary_prompt()),
        HumanMessage(content=conversation),
    ])
    updates["conversation_summary"] = summary_response.content.strip()
    return updates

def rewrite_query(state: State):
    last_message = state["messages"][-1]
    current_query = str(last_message.content).strip()
    conversation_summary = state.get("conversation_summary", "").strip()
    pending_query = state.get("pendingQuery", "").strip()
    pending_clarifications = state.get("pendingClarifications", [])
    recent_messages = _recent_conversation(state["messages"], pending_query)

    context_parts = []
    if conversation_summary:
        context_parts.append(f"Conversation Summary:\n{conversation_summary}")
    if recent_messages:
        context_parts.append(f"Recent Conversation:\n{_format_conversation(recent_messages)}")

    if pending_query:
        clarifications = [*pending_clarifications, current_query]
        clarification_text = "\n".join(
            f"{index}. {value}" for index, value in enumerate(clarifications, start=1)
        )
        context_parts.append(
            f"Unresolved User Query:\n{pending_query}\n\n"
            f"User Clarifications:\n{clarification_text}"
        )
        original_query = f"{pending_query}\nClarifications:\n{clarification_text}"
    else:
        clarifications = []
        context_parts.append(f"User Query:\n{current_query}")
        original_query = current_query

    context_section = "\n\n".join(context_parts)
    llm_with_structure = llm.with_structured_output(QueryAnalysis)
    response = llm_with_structure.invoke([SystemMessage(content=get_rewrite_query_prompt()), HumanMessage(content=context_section)])
    clarification_message_update = (
        [_name_internal_message(last_message, "clarification_response")]
        if pending_query else []
    )

    if response.questions and response.is_clear:
        return {
            "questionIsClear": True,
            "originalQuery": original_query,
            "pendingQuery": "",
            "pendingClarifications": [],
            "rewrittenQuestions": response.questions,
            "messages": clarification_message_update,
        }

    clarification = response.clarification_needed if response.clarification_needed and len(response.clarification_needed.strip()) > 10 else "I need more information to understand your question."
    return {
        "questionIsClear": False,
        "originalQuery": "",
        "pendingQuery": pending_query or current_query,
        "pendingClarifications": clarifications,
        "rewrittenQuestions": [],
        "messages": clarification_message_update + [
            AIMessage(content=clarification, name="clarification")
        ],
    }

def request_clarification(state: State):
    return {}

def route_after_rewrite(state: State) -> Literal["request_clarification", "agent"]:
    if not state.get("questionIsClear", False):
        return "request_clarification"
    else:
        return [
                Send("agent", {"question": query, "question_index": idx, "messages": []})
                for idx, query in enumerate(state["rewrittenQuestions"])
            ]

def aggregate_answers(state: State):
    messages = state.get("messages", [])
    plain_messages = [msg for msg in messages if _is_plain_conversation_message(msg)]
    keep_ids = {getattr(msg, "id", None) for msg in plain_messages[-PRE_ANSWER_HISTORY_MESSAGES_TO_KEEP:]}
    keep_ids.discard(None)
    removals = _remove_messages_not_in(messages, keep_ids)

    if not state.get("agent_answers"):
        return {"messages": removals + [AIMessage(content="No answers were generated.")]}

    sorted_answers = sorted(state["agent_answers"], key=lambda x: x["index"])

    formatted_answers = ""
    for i, ans in enumerate(sorted_answers, start=1):
        formatted_answers += (f"\nRetrieved response {i}:\n"f"{ans['answer']}\n")

    user_message = HumanMessage(content=f"""Original user question: {state["originalQuery"]}\nRetrieved answers:{formatted_answers}""")
    synthesis_response = llm.invoke([SystemMessage(content=get_aggregation_prompt()), user_message])
    return {"messages": removals + [AIMessage(content=synthesis_response.content)]}

---

#### Agent Subgraph Nodes & Edges

def orchestrator(state: AgentState):
    context_summary = state.get("context_summary", "").strip()
    sys_msg = SystemMessage(content=get_orchestrator_prompt())
    summary_injection = (
        [HumanMessage(content=f"[COMPRESSED CONTEXT FROM PRIOR RESEARCH]\n\n{context_summary}")]
        if context_summary else []
    )
    if not state.get("messages"):
        human_msg = HumanMessage(content=state["question"], name="agent_question")
        force_search = HumanMessage(content="YOU MUST CALL 'search_child_chunks' AS THE FIRST STEP TO ANSWER THIS QUESTION.")
        response = llm_with_tools.invoke([sys_msg] + summary_injection + [human_msg, force_search])
        response = _name_internal_message(response, "agent_response")
        return {"messages": [human_msg, response], "tool_call_count": len(response.tool_calls or []), "iteration_count": 1}

    response = llm_with_tools.invoke([sys_msg] + summary_injection + state["messages"])
    response = _name_internal_message(response, "agent_response")
    tool_calls = response.tool_calls if hasattr(response, "tool_calls") else []
    return {"messages": [response], "tool_call_count": len(tool_calls) if tool_calls else 0, "iteration_count": 1}

def route_after_orchestrator_call(state: AgentState) -> Literal["tools", "fallback_response", "collect_answer"]:
    iteration = state.get("iteration_count", 0)
    tool_count = state.get("tool_call_count", 0)

    last_message = state["messages"][-1]
    tool_calls = getattr(last_message, "tool_calls", None) or []

    if not tool_calls:
        return "collect_answer"

    # Accept a final answer at the iteration boundary, but do not execute
    # tool calls that would exceed the configured research budget.
    if iteration >= MAX_ITERATIONS or tool_count > MAX_TOOL_CALLS:
        return "fallback_response"

    return "tools"

def fallback_response(state: AgentState):
    seen = set()
    unique_contents = []
    for m in state["messages"]:
        if isinstance(m, ToolMessage) and m.content not in seen:
            unique_contents.append(m.content)
            seen.add(m.content)

    context_summary = state.get("context_summary", "").strip()

    context_parts = []
    if context_summary:
        context_parts.append(f"## Compressed Research Context (from prior iterations)\n\n{context_summary}")
    if unique_contents:
        context_parts.append(
            "## Retrieved Data (current iteration)\n\n" +
            "\n\n".join(f"--- DATA SOURCE {i} ---\n{content}" for i, content in enumerate(unique_contents, 1))
        )

    context_text = "\n\n".join(context_parts) if context_parts else "No data was retrieved from the documents."

    prompt_content = (
        f"USER QUERY: {state.get('question')}\n\n"
        f"{context_text}\n\n"
        f"INSTRUCTION:\nProvide the best possible answer using only the data above."
    )
    response = llm.invoke([SystemMessage(content=get_fallback_response_prompt()), HumanMessage(content=prompt_content)])
    response = _name_internal_message(response, "agent_response")
    return {"messages": [response]}

def should_compress_context(state: AgentState) -> Command[Literal["compress_context", "orchestrator"]]:
    messages = state["messages"]

    new_ids: Set[str] = set()
    for msg in reversed(messages):
        if isinstance(msg, AIMessage) and getattr(msg, "tool_calls", None):
            for tc in msg.tool_calls:
                if tc["name"] == "retrieve_parent_chunks":
                    raw = tc["args"].get("parent_id") or tc["args"].get("id") or tc["args"].get("ids") or []
                    if isinstance(raw, str):
                        new_ids.add(f"parent::{raw}")
                    else:
                        new_ids.update(f"parent::{r}" for r in raw)

                elif tc["name"] == "search_child_chunks":
                    query = tc["args"].get("query", "")
                    if query:
                        new_ids.add(f"search::{query}")
            break

    updated_ids = state.get("retrieval_keys", set()) | new_ids

    current_token_messages = estimate_context_tokens(messages)
    current_token_summary = estimate_context_tokens([HumanMessage(content=state.get("context_summary", ""))])
    current_tokens = current_token_messages + current_token_summary

    max_allowed = BASE_TOKEN_THRESHOLD + int(current_token_summary * TOKEN_GROWTH_FACTOR)

    goto = "compress_context" if current_tokens > max_allowed else "orchestrator"
    return Command(
        update={
            "retrieval_keys": updated_ids,
            "retrieved_contexts": _retrieval_contexts(messages),
        },
        goto=goto,
    )

def compress_context(state: AgentState):
    messages = state["messages"]
    existing_summary = state.get("context_summary", "").strip()

    if not messages:
        return {}

    conversation_text = f"USER QUESTION:\n{state.get('question')}\n\nConversation to compress:\n\n"
    if existing_summary:
        conversation_text += f"[PRIOR COMPRESSED CONTEXT]\n{existing_summary}\n\n"

    for msg in messages[1:]:
        if isinstance(msg, AIMessage):
            tool_calls_info = ""
            if getattr(msg, "tool_calls", None):
                calls = ", ".join(f"{tc['name']}({tc['args']})" for tc in msg.tool_calls)
                tool_calls_info = f" | Tool calls: {calls}"
            conversation_text += f"[ASSISTANT{tool_calls_info}]\n{msg.content or '(tool call only)'}\n\n"
        elif isinstance(msg, ToolMessage):
            tool_name = getattr(msg, "name", "tool")
            conversation_text += f"[TOOL RESULT — {tool_name}]\n{msg.content}\n\n"

    summary_response = llm.invoke([SystemMessage(content=get_context_compression_prompt()), HumanMessage(content=conversation_text)])
    new_summary = summary_response.content

    retrieved_ids: Set[str] = state.get("retrieval_keys", set())
    if retrieved_ids:
        parent_ids = sorted(r for r in retrieved_ids if r.startswith("parent::"))
        search_queries = sorted(r.replace("search::", "") for r in retrieved_ids if r.startswith("search::"))

        block = "\n\n---\n**Already executed (do NOT repeat):**\n"
        if parent_ids:
            block += "Parent chunks retrieved:\n" + "\n".join(f"- {p.replace('parent::', '')}" for p in parent_ids) + "\n"
        if search_queries:
            block += "Search queries already run:\n" + "\n".join(f"- {q}" for q in search_queries) + "\n"
        new_summary += block

    return {"context_summary": new_summary, "messages": [RemoveMessage(id=m.id) for m in messages[1:]]}

def collect_answer(state: AgentState):
    last_message = state["messages"][-1]
    is_valid = isinstance(last_message, AIMessage) and last_message.content and not last_message.tool_calls
    answer = last_message.content if is_valid else "Unable to generate an answer."
    return {
        "final_answer": answer,
        "agent_answers": [{
            "index": state["question_index"],
            "question": state["question"],
            "answer": answer,
            "contexts": state.get("retrieved_contexts", []),
        }]
    }

Why this architecture? - Summarization maintains conversational context without overwhelming the LLM - Query rewriting ensures search queries are precise and unambiguous, using context intelligently - Human-in-the-loop catches unclear queries before wasting any retrieval resources - Parallel execution via Send API spawns independent agent subgraphs for each sub-question simultaneously - Context compression keeps the agent's working memory lean across long retrieval loops, preventing redundant fetches - Fallback response ensures graceful degradation — the agent always returns something useful even when the budget runs out - Answer collection & aggregation extracts clean final answers from agents and aggregates them into a single coherent response ---

Step 10: Build the LangGraph Graphs

Assemble the complete workflow graph with conversation memory and multi-agent architecture.

from langgraph.graph import START, END, StateGraph
from langgraph.prebuilt import ToolNode
from langgraph.checkpoint.memory import InMemorySaver

checkpointer = InMemorySaver()

agent_builder = StateGraph(AgentState)
agent_builder.add_node(orchestrator)
agent_builder.add_node("tools", ToolNode([search_child_chunks, retrieve_parent_chunks]))
agent_builder.add_node(compress_context)
agent_builder.add_node(fallback_response)
agent_builder.add_node(should_compress_context)
agent_builder.add_node(collect_answer)

agent_builder.add_edge(START, "orchestrator")
agent_builder.add_conditional_edges("orchestrator", route_after_orchestrator_call, {"tools": "tools", "fallback_response": "fallback_response", "collect_answer": "collect_answer"})
agent_builder.add_edge("tools", "should_compress_context")
agent_builder.add_edge("compress_context", "orchestrator")
agent_builder.add_edge("fallback_response", "collect_answer")
agent_builder.add_edge("collect_answer", END)
agent_subgraph = agent_builder.compile()

graph_builder = StateGraph(State)
graph_builder.add_node(summarize_history)
graph_builder.add_node(rewrite_query)
graph_builder.add_node(request_clarification)
graph_builder.add_node("agent", agent_subgraph)
graph_builder.add_node(aggregate_answers)

graph_builder.add_edge(START, "summarize_history")
graph_builder.add_edge("summarize_history", "rewrite_query")
graph_builder.add_conditional_edges("rewrite_query", route_after_rewrite)
graph_builder.add_edge("request_clarification", "rewrite_query")
graph_builder.add_edge(["agent"], "aggregate_answers")
graph_builder.add_edge("aggregate_answers", END)

agent_graph = graph_builder.compile(checkpointer=checkpointer, interrupt_before=["request_clarification"])

Graph architecture explained:

The architecture flow diagram can be viewed here.

Agent Subgraph (processes individual questions): - START → orchestrator (invoke LLM with tools) - orchestratortools (if tool calls needed) OR fallback_response (if budget exhausted) OR collect_answer (if done) - toolsshould_compress_context (check token budget) - should_compress_contextcompress_context (if threshold exceeded) OR orchestrator (otherwise) - compress_contextorchestrator (resume with compressed memory) - fallback_responsecollect_answer (package best-effort answer) - collect_answer → END (clean final answer with index)

Main Graph (orchestrates complete workflow): - START → summarize_history (roll older chat into summary and keep only recent exchanges) - summarize_historyrewrite_query (rewrite query with context, check clarity) - rewrite_queryrequest_clarification (if unclear) OR spawn parallel agent subgraphs via Send (if clear) - request_clarificationrewrite_query (after user provides clarification) - All agent subgraphs → aggregate_answers (merge all responses) - aggregate_answers → END (return final synthesized answer)

---

Installation & Usage

Sample pdf files can be found here: javascript, blockchain, fortinet_TMP.pdf).

Option 3: Docker Deployment

See project/README.md for full Docker instructions and system requirements.

Example Conversations

With Conversation Memory:

User: "How do I install SQL?"
Agent: [Provides installation steps from documentation]

User: "How do I update it?"
Agent: [Understands "it" = SQL, provides update instructions]

With Query Clarification:

User: "Tell me about that thing"
Agent: "I need more information. What specific topic are you asking about?"

User: "The installation process for PostgreSQL"
Agent: [Retrieves and answers with specific information]

---

LLM Provider Configuration

This system is provider-agnostic: the runnable app uses Ollama by default, and the chat model initialization can be adapted to any LLM provider available in LangChain. The examples below cover the most common options, but the same pattern applies to any other supported provider.

Note: Model names change frequently. Always check the official documentation for the latest available models and their identifiers before deploying.

Step 2: Configure Vector Database

Set up Qdrant to store child chunks with hybrid search capabilities.

from qdrant_client.http import models as qmodels
from langchain_qdrant import QdrantVectorStore
from langchain_qdrant.qdrant import RetrievalMode

embedding_dimension = len(dense_embeddings.embed_query("test"))

def ensure_collection(collection_name):
    if not client.collection_exists(collection_name):
        client.create_collection(
            collection_name=collection_name,
            vectors_config=qmodels.VectorParams(
                size=embedding_dimension,
                distance=qmodels.Distance.COSINE
            ),
            sparse_vectors_config={
                "sparse": qmodels.SparseVectorParams()
            },
        )

---

Step 8: Agent Configuration

Hard limits on tool calls and iterations prevent infinite loops. Token counting (via tiktoken) drives context compression decisions.

import tiktoken
from functools import lru_cache

MAX_TOOL_CALLS = 8       # Maximum tool calls per agent run
MAX_ITERATIONS = 10      # Maximum agent loop iterations
BASE_TOKEN_THRESHOLD = 2000     # Initial token threshold for compression
TOKEN_GROWTH_FACTOR = 0.9       # Multiplier applied after each compression

@lru_cache(maxsize=1)
def _get_token_encoding():
    try:
        return tiktoken.encoding_for_model("gpt-4")
    except Exception:
        try:
            return tiktoken.get_encoding("cl100k_base")
        except Exception:
            return None

def estimate_context_tokens(messages: list) -> int:
    contents = [
        str(msg.content)
        for msg in messages
        if hasattr(msg, "content") and msg.content
    ]
    encoding = _get_token_encoding()
    if encoding is None:
        return sum(max(1, len(content) // 4) for content in contents)
    return sum(len(encoding.encode(content)) for content in contents)

---

Option A: pip

python -m venv .venv && source .venv/bin/activate pip install -r requirements.txt

Option B: uv

uv venv .venv source .venv/bin/activate # Windows: .venv\Scripts\activate uv pip install -r requirements.txt


#### 2. Run the Application
bash python project/app.py ```

3. Ask Questions

Open the local URL (e.g., http://127.0.0.1:7860) to start chatting.

---

Step 11: Create Chat Interface

Build a Gradio interface with conversation persistence and human-in-the-loop support. For a complete end-to-end pipeline Gradio interface, including document ingestion, please refer to project/README.md.

Note: The notebook and full project stream the final aggregated answer while showing query analysis and tool activity in separate collapsible blocks. Raw orchestrator, compression, and fallback model output remains internal. The example below is intentionally minimal.
import gradio as gr
import uuid

def create_thread_id():
    """Generate a unique thread ID for each conversation"""
    return {"configurable": {"thread_id": str(uuid.uuid4())}, "recursion_limit": 50}

def clear_session():
    """Clear thread for new conversation"""
    global config
    agent_graph.checkpointer.delete_thread(config["configurable"]["thread_id"])
    config = create_thread_id()

def chat(message, history):
    current_state = agent_graph.get_state(config)

    if current_state.next:
        agent_graph.update_state(config,{"messages": [HumanMessage(content=message.strip())]})
        result = agent_graph.invoke(None, config)
    else:
        result = agent_graph.invoke({"messages": [HumanMessage(content=message.strip())]}, config)

    return result['messages'][-1].content

config = create_thread_id()

with gr.Blocks() as demo:
    chatbot = gr.Chatbot()
    chatbot.clear(clear_session)
    gr.ChatInterface(fn=chat, chatbot=chatbot)

demo.launch(theme=gr.themes.Citrus())

You're done! You now have a fully functional Agentic RAG system with conversation memory, hierarchical indexing, and human-in-the-loop query clarification.

---

Query Processing: Four-Stage Intelligent Workflow

User Query → Conversation Summary → Query Rewriting → Query Clarification →
Parallel Agent Reasoning → Aggregation → Final Response

Stage 1 — Conversation Understanding: Maintains a rolling summary and recent conversation history to preserve continuity without indefinitely increasing context size.

Stage 2 — Query Clarification: Resolves references ("How do I update it?" → "How do I update SQL?"), splits multi-part questions into focused sub-queries, detects unclear inputs, and rewrites queries for optimal retrieval. Pauses for human input when clarification is needed.

Stage 3 — Intelligent Retrieval (Multi-Agent Map-Reduce): Spawns parallel agent subgraphs — one per sub-query. Each agent searches child chunks, fetches parent chunks for context, self-corrects if results are insufficient, compresses context to avoid redundant fetches, and falls back gracefully if the search budget is exhausted.

Example: "What is JavaScript? What is Python?" → 2 parallel agents execute simultaneously.

Stage 4 — Response Generation: Aggregates all agent responses into a single coherent answer.

---

Troubleshooting

AreaCommon ProblemsSuggested Solutions
**Model Selection**- Responses ignore instructions<br>- Tools (retrieval/search) used incorrectly<br>- Poor context understanding<br>- Hallucinations or incomplete aggregation- Use more capable LLMs<br>- Prefer models 8B+ for better reasoning<br>- Consider cloud-based models if local models are limited
**System Prompt Behavior**- Model answers without retrieving documents<br>- Query rewriting loses context<br>- Aggregation introduces hallucinations- Make retrieval explicit in system prompts<br>- Keep query rewriting close to user intent
**Retrieval Configuration**- Relevant documents not retrieved<br>- Too much irrelevant information- Increase retrieved chunks (k) or lower similarity thresholds to improve recall<br>- Reduce k or increase thresholds to improve precision
**Chunk Size / Document Splitting**- Answers lack context or feel fragmented<br>- Retrieval is slow or embedding costs are high- Increase chunk & parent sizes for more context<br>- Decrease chunk sizes to improve speed and reduce costs
**Context Compression**- Agent loses important details after compression<br>- Compressed summaries are too vague- Tune the compression system prompt<br>- Increase BASE_TOKEN_THRESHOLD to delay compression<br>- Increase TOKEN_GROWTH_FACTOR
**Agent Configuration**- Agent gives up too early <br>- Agent loops too long- Increase MAX_TOOL_CALLS / MAX_ITERATIONS for complex queries<br>- Decrease them to speed up simple queries
**Temperature & Consistency**- Responses inconsistent or overly creative<br>- Responses too rigid or repetitive- Set temperature to 0 for factual, consistent output<br>- Slightly increase temperature for summarization or analysis tasks
**Embedding Model Quality**- Poor semantic search<br>- Weak performance on domain-specific or multilingual docs- Use higher-quality or domain-specific embeddings<br>- Re-index all documents after changing embeddings
💡 For additional troubleshooting tips see the README Troubleshooting.
🇨🇳 中文文档镜像 AI 翻译 2026-05-27
英文原文章节由系统翻译为中文摘要,便于快速理解。完整原文见上方 "📑 README 深度解析"。
📌 简介

本项目名为 Agentic RAG for Dummies,旨在通过极简的代码实现一个基于 LangGraph 的 Agentic RAG(检索增强生成)系统。不同于仅展示基础概念的传统 RAG 教程,本项目提供了一个可扩展的架构,帮助开发者构建具备模块化设计、对话记忆能力以及 Human-in-the-loop(人工介入)查询澄清机制的智能 Agent 系统,填补了从理论到工程实践之间的鸿沟。

⚡ 功能介绍

本项目集成了多项高级 RAG 特性:通过 Hierarchical Indexing(层级索引)实现精准的小分块搜索与大 Parent 块上下文检索;内置 Conversation Memory(对话记忆)以维持自然对话的上下文连贯性;具备 Query Clarification(查询澄清)功能,能够自动重写模糊查询或暂停并询问用户以获取细节;最后通过 LangGraph 进行 Agent Orchestration(智能体编排),协调整个检索与推理流程。

🛠 安装步骤(Docker/pip/源码)

首先,您需要从 https://ollama.com 下载并安装 Ollama。随后,通过命令行执行 `ollama pull qwen3:4b-instruct-2507-q4_K_M` 来获取本地模型。在 Python 环境中,请使用 `pip install -r requirements.txt` 安装必要的依赖库。需要注意的是,为了确保可靠的 Tool Calling(工具调用)和指令遵循能力,建议优先使用参数量在 7B 以上的模型,较小的模型可能会出现忽略检索指令或产生幻觉的情况。

🚀 使用教程

本项目提供了灵活的使用方式。推荐使用 Google Colab 进行快速测试,只需点击 README 顶部的 Open in Colab 徽章,上传 PDF 文档至 `docs/` 目录并运行所有单元格即可。如果您希望在本地环境(如 Jupyter 或 VSCode)运行,请先创建并激活虚拟环境,安装依赖后将您的 PDF 文件放入 `docs/` 文件夹。系统支持带有记忆功能的对话,能够理解如“如何更新它?”这类依赖上下文的指代性问题。

⚙️ 配置说明(含 MCP / env)

系统采用了 Provider-agnostic(供应商无关)的设计理念,支持任何在 LangChain 中集成的 LLM 提供商。您只需通过修改一行代码即可轻松切换不同的模型后端。在配置 Vector Database(向量数据库)时,系统使用 Qdrant 来存储子分块,并支持 Hybrid Search(混合搜索)能力。请务必根据所选模型的实际名称进行配置,以确保流程的稳定性。

🔌 API 说明

本项目通过 Gradio 构建了完整的 Chat Interface(聊天界面),支持对话持久化以及 Human-in-the-loop(人工介入)机制。该接口不仅能处理用户提问,还支持完整的 Streaming(流式输出),包括推理步骤(Reasoning steps)和工具调用(Tool calls)的实时展示。对于需要端到端文档摄取与处理的完整流水线,开发者可以参考项目中的详细文档。

🔄 工作流/模块

系统采用四阶段智能工作流进行查询处理:首先进入 Conversation Understanding(对话理解)阶段,分析历史记录以提取上下文;随后进入 Query Rewriting(查询重写)与 Query Clarification(查询澄清)阶段,确保意图准确;接着通过 Parallel Agent Reasoning(并行智能体推理)进行处理;最后经过 Aggregation(结果聚合)生成最终的响应,确保整个过程既智能又受控。

❓ FAQ 摘要

在常见问题排查中,开发者应重点关注 Model Selection(模型选择)。如果遇到响应忽略指令、工具调用(如检索/搜索)不当、上下文理解能力差或出现幻觉(Hallucinations)等问题,通常是因为使用的 LLM 能力不足。建议升级到更强大的模型以提升系统的逻辑推理与指令遵循能力。

🎯 aiskill88 AI 点评 A 级 2026-05-20

优质开源学习资源,模块化设计清晰,LangGraph官方认可度高。3k+星标印证其实用价值,Notebook形式降低入门门槛,持续维护品质稳定。

📚 实用指南(长尾问题)
适合谁
  • 构建多智能体协作系统的 Agent 开发者
  • 构建企业知识库 / RAG 检索应用的团队
最佳实践
  • 生产部署优先使用 Docker Compose 隔离依赖,并挂载 volume 持久化数据
  • 本地部署优先选 GGUF 量化模型,节省显存并保持响应速度
  • 分块大小建议 256-512 tokens,向量库优选 pgvector 或 Qdrant
  • Agent 任务先做 dry-run 验证工具调用链,再开启自主执行
常见错误
  • API key 直接提交到 git 仓库(请用 .env 并加入 .gitignore)
  • 容器内无法访问宿主机 localhost — 使用 host.docker.internal
  • embedding 模型与查询模型不一致导致检索失效
  • 显存不足直接 OOM — 优先降低 context 或换更小的量化模型
部署方案
  • Docker:agentic-rag-for-dummies 提供官方镜像,docker compose up 一键启动
  • 本地部署:CPU 8GB 起,GPU 推荐 16GB+ 显存
  • 云端托管:可放在 Vercel / Railway / Fly.io 等 PaaS 平台
相关搜索
agentic-rag-for-dummies 中文教程agentic-rag-for-dummies 安装报错怎么办agentic-rag-for-dummies Docker 部署agentic-rag-for-dummies Agent 工作流agentic-rag-for-dummies 与同类工具对比agentic-rag-for-dummies 最佳实践agentic-rag-for-dummies 适合谁用

⚡ 核心功能

👥 适合谁
  • 构建多智能体协作系统的 Agent 开发者
  • 构建企业知识库 / RAG 检索应用的团队
⭐ 最佳实践
  • 生产部署优先使用 Docker Compose 隔离依赖,并挂载 volume 持久化数据
  • 本地部署优先选 GGUF 量化模型,节省显存并保持响应速度
  • 分块大小建议 256-512 tokens,向量库优选 pgvector 或 Qdrant
  • Agent 任务先做 dry-run 验证工具调用链,再开启自主执行
⚠️ 常见错误
  • API key 直接提交到 git 仓库(请用 .env 并加入 .gitignore)
  • 容器内无法访问宿主机 localhost — 使用 host.docker.internal
  • embedding 模型与查询模型不一致导致检索失效
  • 显存不足直接 OOM — 优先降低 context 或换更小的量化模型

👥 适合人群

自动化工程师和运维人员项目经理和业务分析师希望减少重复性工作的专业人士数字化转型团队

🎯 使用场景

  • 自动化日常重复性工作,将精力集中于创造性任务
  • 构建数据采集 → 处理 → 输出的完整自动化管线
  • 实现跨平台、跨系统的数据流转和业务协同

⚖️ 优点与不足

✅ 优点
  • +MIT 协议,可免费商用
  • +大幅减少重复性人工操作
  • +可视化流程,清晰直观
  • +可扩展性强,支持复杂场景
⚠️ 不足
  • 初始配置和调试需投入一定时间
  • 强依赖外部服务的稳定性
  • 复杂场景需具备一定技术基础
⚠️ 使用须知

AI Skill Hub 为第三方内容聚合平台,本页面信息基于公开数据整理,不对工具功能和质量作任何法律背书。

建议在沙箱或测试环境中充分验证后,再部署至生产环境,并做好必要的安全评估。

📄 License 说明

✅ MIT 协议 — 最宽松的开源协议之一,可自由商用、修改、分发,仅需保留版权声明。

🔗 相关工具推荐

📚 相关教程推荐
📰 相关 AI 新闻
🍿 AI 圈相关吃瓜
🗺️ 相关解决方案
🧩 你可能还需要
基于当前 Skill 的能力图谱,自动补全的工具组合

❓ 常见问题 FAQ

非常适合。通过Jupyter Notebook逐步讲解,降低学习难度,适合想入门RAG的开发者。
💡 AI Skill Hub 点评

总体来看,agentic-rag-for-dummies Agent工作流 是一款质量优秀的Agent工作流,在同类工具中具备一定竞争力。AI Skill Hub 将持续追踪其更新动态,建议收藏备用,结合自身场景选择合适时机引入使用。

⬇️ 获取与下载
⬇ 下载源码 ZIP

✅ MIT 协议 · 可免费商用 · 直接从 aiskill88 服务器下载,无需跳转 GitHub

📚 深入学习 agentic-rag-for-dummies Agent工作流
查看分步骤安装教程和完整使用指南,快速上手这款工具
🌐 原始信息
原始名称 agentic-rag-for-dummies
原始描述 开源AI工作流:A modular Agentic RAG built with LangGraph — learn Retrieval-Augmented Generatio。⭐3.3k · Jupyter Notebook
Topics RAGAgentLangGraph工作流学习教程
GitHub https://github.com/GiovanniPasq/agentic-rag-for-dummies
License MIT
语言 Jupyter Notebook
🔗 原始来源
🐙 GitHub 仓库  https://github.com/GiovanniPasq/agentic-rag-for-dummies

收录时间:2026-05-18 · 更新时间:2026-05-19 · License:MIT · AI Skill Hub 不对第三方内容的准确性作法律背书。

📺 订阅 AI Skill Hub Daily Telegram 频道
每天 8 条精选 AI Skill、MCP、Agent 与自动化工具推送
加入频道 →
